MB-350 Plastic Cup Lid Forming Machine

MB-350 Plastic Cup Lid Forming Machine

Introduction
Plastic cup lid machine or plastic cup lid forming machine adopts a fully automatic blow molding or plastic suction molding, punching and die cutting required by users. This cup lid making machine enjoys advanced technology and features safe and simple operation that will reduce labor consumption. Possessing economical and practical properties, it is widely used to the production in food, medicine and hardware. MB-350 plastic cup lid forming machine can be also applicable to plastic wares such as HIPS, PS, PVC, PET, PE medicine trays and cup lid thermoforming boxes. Mingbo plastic cup lid making machines are greatly favored by customers both at home and abroad.

Features
1. The main parts of plastic cup lid forming machine include motor, heating body, cylinder and cam.
2. Our plastic cup lid making machines realize GMP or QS double standard dust-free purification production. This improves products' hygiene and safety and solves cross-contamination.
3. Unwinding, molding, punching, blanking and rolling can be done synchronously. MB-350 plastic cup lid forming machine enjoys compact structure, smooth operation and easy operation.
4. It adopts special feeding device that can save 20 times electric power. Besides, special punching device can save five percent of  materials.
5. This cup lid making machine features adjustable stroke and easy mold replacement. Customers can easily replace section sizes to fit a variety of specifications of products.
6. Our plastic cup lid forming machines possess stepless frequency control and PC circuit control panel.
7. The max feeding width of plastic cup lid machine is 350 mm and the lid size is from 30 to 120 mm.
8. We can design different moulds according to users' needs.

Packaging and Transportation of MB-350 Plastic Cup Lid Making Machine
We use wooden cases to package plastic cup lid forming machines, which is convenient for sea transportation.

Technical Parameters of MB-350 Plastic Cup Lid Machine

Cutting Frequency 15 to 45 times/min
Power 380V/220V/50Hz
Stroke Adjustable Range 30t o 160 mm
Max. Forming Depth 30 mm, 45 mm, 60 mm
Max. Forming Area 350 mm × 160 mm
Capacity 3600 to 6000 pcs/h
Motor Power 1.5 Kw
Consumption over 0.2 m3/min
Pressure 0.4 to 0.7 Mpa
Overall Dimension 2500 mm × 900 mm × 1600 mm
Weight 800 kg
